Orient LR-60 Line Detector - Outlet
Only 3 item(s) are currently left in stock
Couldn't load pickup availability
Free DPD Delivery
Order before 3:45PM each working day, for DPD delivery in 3 to 5 working days (Mon-Fri).
GPS tracked to your Door & 1-Hour delivery window.
Automatic Discount
Outlet products are typically cheaper than normal retail versions because some items may have small cosmetic flaws that don’t affect functionality but keep them from being sold at full price.
1-Year Warranty
This Outlet product will be inspected, checked and prepared by our technicians.
About this Product
Orient LR-60 Line Detector
This is an accurate but competitively priced Laser Line Detector, supplied by Orient Surveying Company.
It extends the range of most Orient "pulse output" RED line lasers up to 40m (approx. 50m range with Orient LP360R) for both indoor & outdoor site work.
Features
Working range 40m (LP360R: 50m)
For use only with Orient RED beam "pulse output" lasers
Audible indication of line level
Visual LED indication of line level
Mounting clamp bracket included for use with staffs/rods
Waterproof to IP43
Outlet Warranty: 1 Year
Specification
Detection accuracy: +/-1mm or less
Nominal frequency: 10kHz
Laser reception window: 20x20mm, working height 15mm
LED's: Red, blue
Audible tone: Loud/normal/OFF (selectable)
Auto power off approx. 10 minutes
Power voltage: 9V dc
Power supply: 1 x 9V alkaline battery
Low power alert function: Yes
Continuous operating time: approx. 15 hrs
Waterproof: Yes to IP43
Operating temperature range: -10 to +40 deg C
Storage temperature range: -10 to +50 deg C
Instrument size: 150 x 50 x 26 (mm)
Weight: 150 grams with battery.
Compatibility
Please check compatibility below:
| Model | Compatible |
| Orient LP103 | Yes |
| Orient LP412 | Yes |
| Orient LP512 | Yes |
| Orient LP514 | Yes |
| Orient LP618 | Yes |
| Orient LP360R | Yes |
| Any other Brand or Model | No |
Comprises of
Orient LR-60 Detector
9V Alkaline Battery
Staff Mounting Bracket
Outlet Warranty: 1 Year
